Advanced Coil offers several types of housings that will accommodate virtually any application regardless of operating temperatures, pressures or environmental conditions. These unites are all custom manufactured to meet your application requirements.

Slide-Out Housings

Slide-out housings are used in applications where the coil(s) need to be easily removed, to facilitate inspection, cleaning or replacement.

Airtight Housings

Airtight housings are built to ensure that there is no cross-contamination between the process air stream and the environment.

Design Features

Pressure Sealing

Welded housings can be designed to accommodate a range of pressures from a full vacuum to over 100 psig. Lower pressure/non-critical housings may utilize a bolted type of construction with gasketed and/or silicone caulked joints.

ASME Pressure Vessel Construction

Housings built and “U” stamped in accordance with Section VIII, Division 1 of the ASME Pressure Vessel Code are available, when required, on all of our welded custom high pressure housings. All items may also be National Board registered or CRN stamped if required or requested.

Airside Transitions

Transitions can be designed with square, rectangle or round openings. High pressure housings are generally transitioned to round welded or flanged connection.

Optional features

  • Inspection and Access Panels
  • Drip pans for condensate and/or cleaning solution collection
  • Structural legs
  • Custom mounting configurations
  • Lifting and installation brackets
  • Support structures
  • Face and bypass dampers
  • Integrated filter sections

Heat Exchanger Applications

Advanced Coil manufactures housing heat exchangers for a variety of applications including:
  • Grain/seed processing facilities and equipment
  • Pulp/paper processing facilities and equipment
  • Dairy processing facilities and equipment
  • Food processing facilities and equipment
  • Power plants
  • Heat recovery systems
  • Petroleum/chemical plants
  • Textile factories

Specifications

Standard Materials

  • Galvanized Steel: 16 gauge to 7 gauge
  • 304 Stainless Steel: 16 gauge to 1” thick
  • 316 Stainless Steel: 16 gauge to 1” thick
  • Carbon Steel: 16 gauge to ¼” thick
  • Aluminum: 0.060” thick to ¼” thick
